Description
Accurately control the welding depth of different pipes and fittings
Accurate control the depth that pipe insert fittings
The diameter selector can avoid over-melting caused by excessive force when pipes are inserted into pipes
Mechanical operation makes each welding interface Standardization ,improve welding quality.
Accurate control the depth that pipe insert fittings
The diameter selector can avoid over-melting caused by excessive force when pipes are inserted into pipes
Mechanical operation makes each welding interface Standardization ,improve welding quality.
| Model | Prisma125 | Prisma160 |
| Working temperature | 180-280℃ | 180-280℃ |
| Materials | HDPE/PP-R/PPH/PB/PVDF | |
| Rated voltage | 220VAC-50/60HZ | |
| Rated power | 1400W | 2000W |
| Working range | 25-125mm | 75-160mm |
| Dimensions machine working | 1500*840*1260 | 1600*900*1100 |
| Transport case wood | 1500*800*1300 | 1600*920*1150 |
| Weight prisma only | 68-100kg | 78-110kg |
| Weight case wood | 53kg | 60kg |
