Description
| SPECIFICATIONS | |
| CNC Feeding sheet length: | 4000mm |
| Cutting Length: | 4000mm |
| Cutting Thickness: | 60mm |
| Main Motor Power: | 5.5HP |
| Saw size: | 305*25.4*100T |
| Spindle speed: | 4000rpm |
| Driver method: | frequency conversion adjustment |
| CNC feeding Brand: | Taida servo |
| Transmission method: | Precision oblique gear |
| Positioning accuracy: | ±0.1mm |
| Slideway on the feeding frame: | Japan (THK) |
| Pressing method: | pneumatic |
| Dust dusting method: | 3KW bag -type dust collector |
| Controller: | Siemens |
| Slideway: | Japan (THK) |
| Rated voltage: | 380V/50Hz AC power |
| Processing materials: | thermoplastic sheet |
| Dimensions: | 5250mm*5500*1650mm |
| N.W: | 2600kg |
