SWT-PH6000 Sheet Butt Fusion Welder with Vertical Welding - New Design for PP/PE
SWT-PH6000 sheet butt fusion welding machine with vertical welding function
①Welding Line②Welding Circular
③Vertical Welding
Welding length:6000mm
Welding thckness:3.0-50.0mm
Automatic Sheet Rolling Devices with independence control motor
2nd Automatic Sheet Rolling Devices can slide freely on a one-meter guide rail.
When you use a 6-meter welding machine to weld cylinders up to 2 meters in length, it can adjust its position appropriately based on the cylinder's length. This feature was added to ensure better welding of high-quality products.
Let me introduce the New Design of sheet butt fusion welding machine to be released soon.
A group of 23 pieces independently controlled pneumatic suckers in one of beam allows the pp/pe slab to be laid and blocked vertically,
90° welding can therefore be performed without difficulty.
The SWT-PH6000 sheet butt fusion welding machine own each 6-meter beam is divided into two 3-meter sections with independently controlled pneumatic pressure clamp.
there are three control areas: Mechanical buttons, touch screen keys, foot pedals.
Delta's servo motor and lead screw control the lifting and lowering of the heating plate with an accuracy of 0.01mm.
During vertical welding, the contact surface is adjusted according to the thickness of the plate to achieve a perfect welding effect.
As a leading provider of plastic sheet welders in China, MM-Tech has earned the trust of industries such as electroplating, water treatment, environmental protection, aquaculture, shipbuilding, and fire truck manufacturing, thanks to its robust core technology and over 90% in-house research and development and production capabilities.
Applications:
PPH Plating Tanks
Pp Scrubbers
PP Chemical Storage Tanks
PP PE Water Treament Systems
PE Aquachuture Tanks
