Description
| SPECIFICATIONS | |
| CNC Feeding sheet length | 3050mm |
| Cutting Thickness | 60mm |
| Main Motor Power | 5.5HP |
| Saw size | 305*25.4*100T |
| Spindle speed | 4000rpm |
| Driver method | frequency conversion adjustment |
| Transmission method | Precision oblique gear |
| Positioning accuracy | ±0.1mm |
| Slideway on the feeding frame | Japan (THK) |
| Pressing method | pneumatic |
| Dust dusting method | 3KW bag-type dust collector |
| Controller | Siemens |
| Slideway | Japan (THK) |
| Rated voltage | 380V/50Hz AC power |
| Processing materials | thermoplastic sheet |
| Dimensions | 6250mm*5500*1650mm |
| N.W | 2550kg |
